Temperature Indicator & Sensor
FEATURES
=> State of Art Microcontroller Based Design.
=> Relay Out Put for cutoff / Alarm
=> User Programmable Alarm Set Point, Time Delay & CT Ratio.
=> True RMS measurement.
=> Auto Scrolling Facility.
=> Password protection
=> Bar Graph Indication for Load
=> ALARM / TRIP:
- UNDER VOLTAGE
- OVER VOLTAGE
- OVER LOAD
- PHASE SEQUENCE REVERSAL
- PHASE FAILURE
ADVANTAGES
=> To caution on the Load
=> To indentify inefficiency of Machine / Man
=> Reduce Panel Space, Wiring , Installation Time
=> Scale User adjustable reduces inventory
APPLICATION
| Control Panel | Test Bench |
| Distribution Systems | APFC Panel |
| Generator Sets | Energy Management |
| Motor Control | Process Control & SCADA |
PARAMETERS
| Volts : | R-Y Voltage |
| Y-B Voltage | |
| B-R Voltage | |
| R-N Voltage | |
| Y-N Voltage | |
| B-N Voltage | |
| Amps | R Phase |
| Y Phase | |
| B Phase | |
| Frequency : | System |
SPECIFICATION
| System | : | 3 Phase 4 Wire / 3 Phase 3 Wire | ||||||||||||||||||
| Aux. Supply | : | 230V /110VAC 50/60hz (-20% +15%) | ||||||||||||||||||
| Burden on Aux. | : | < 4VA | ||||||||||||||||||
| Voltage Input | : | 110/415/440 VAC ( L – L )500Vmax | ||||||||||||||||||
| Current Input | : | 1 Amps / 5 Amps | ||||||||||||||||||
| Burden on CT | : | < 0.2 VA | ||||||||||||||||||
| Temp | : | -20°C to +55°C | ||||||||||||||||||
| Humidity | : | < 95% RH ( non condensing) | ||||||||||||||||||
| Weight | : | 500 gms | ||||||||||||||||||
| Accuracy: |
|
|||||||||||||||||||
| Resolution: | : |
|
||||||||||||||||||
| Dimension | : |
|
